Acrylic Sheet Bonding Tips

Because acrylic is beautiful and easy to process or dye with a better transparency and chemical characteristics (such as weather resistance), it is often used for display stands, photo frames, boxes, mirrors, crafts and more. Below, we have listed the steps for bonding acrylic sheets together. These sheets are then used in the production of a variety of items.

1. Splicing: Lay the two organic glass plates to be spliced next to each other in a horizontal manner on the operation bench. Place tape on the bottom, and reserve a gap of 0.03mm in which to inject the adhesive. Through this gap, gently inject the adhesive in an even manner with the applicator until the gap is fully closed. Finally, remove the tape after complete curing.

2. Facade bonding: Facade bonding is the most widely used bonding method, often used on acrylic display shelves. The first step is to clean the surface that needs bonding. Then, in order to improve the adhesion quality, the object to be bonded needs to be prevented from shaking. Following that, there are two ways to bond 3mm thick organic glass plates. The first involves the insertion of fine wires before the adhesion, with the wires removed before complete curing. The other option involves using tape before applying the adhesive.

3. Bevel bonding: To avoid the shift in bevel faces, they must be attached using a 90° fixture. Apply adhesive equally and gently to the bevel faces, then remove the template after complete curing.

4. Plane bonding: Plane bonding is a special method. First, clean the boding surface, then lay the piece down horizontally on the operation bench. The adhesive can then be added. Finally, lay another organic glass plate onto the adhesive, being careful not to cause any bubbles.

Warning to acrylic product processing plants: the adhesion process for acrylic boards and organic glass plates is directly affected by environmental conditions, including room temperature, humidity and other factors. Therefore, the room temperature needs to be properly maintained during processing and adhesion processes.
